4 TECHNICAL DATA
16
4.1 chassis tightening torques
Remaining screws, chassis M4 4 Nm (3 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, trim M5 4 Nm (3 lbf ft)
Screw, anti-rotation lock, handle-
bar stub
M5 4 Nm (3 lbf ft)
Screw, side stand sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, wheel speed sensor wheel M5 7 Nm (5.2 lbf ft)
Loctite
®
243™
Nut, tail light M6 7 Nm (5.2 lbf ft)
Remaining nuts, chassis M6 15 Nm (11.1 lbf ft)
Remaining screws, chassis M6 9 Nm (6.6 lbf ft)
Remaining screws, trim M6 6 Nm (4.4 lbf ft)
Screw, chain guard M6 3 Nm (2.2 lbf ft)
Screw, cross connector, seat sup-
port
M6 5 Nm (3.7 lbf ft)
Screw, foot brake cylinder M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, fuel pump M6 10 Nm (7.4 lbf ft)
Screw, fuel tank attachment, lat-
eral, on frame
M6 11 Nm (8.1 lbf ft)
Screw, handlebar stub M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, magnetic holder on side
stand
M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Nut, rear sprocket screw M8 38 Nm (28 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 30 Nm (22.1 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, connecting plate, frame,
subframe
M8 19 Nm (14 lbf ft)
Screw, foot brake lever M8 16 Nm (11.8 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, fuel tank attachment, front,
on frame
M8 20 Nm (14.8 lbf ft)
Screw, handlebar clamp M8 15 Nm (11.1 lbf ft)
Screw, mirror holder M8 19 Nm (14 lbf ft)
Screw, passenger footrest unit M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, rear brake disc M8 29 Nm (21.4 lbf ft)
Loctite
®
243™
Screw, shift lever M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
