5IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by KUBOTA.
Use with implements which are not sold or approved by KUBOTA and which exceed the maximum specifications listed
below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor,
damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use
with improper implements are not covered by the warranty.]
A Implement size may vary depending on soil operating conditions.
Tread (max.width) with farm tires Lower link end max.
loading weight
W0
Front Rear
B2320DTN 705 mm (27.8 in.) 750 mm (29.5 in.)
300 kg (660 lbs.)
B2320HSDN 780 mm (30.7 in.) 750 mm (29.5 in.)
B2320DT
B2320HSD
800 mm (31.5 in.) 900 mm (35.4 in.)
B2620HSD
B2920HSD
815 mm (32.1 in.) 950 mm (37.4 in.)
Actual figures
B2320
B2620
B2920
Implement weight W1
and / or size
Max. Drawbar
Load W2
Trailer loading weight
W3
Max. capacity
As in the following list
(Shown on the next page)
300 kg (660 lbs.) 1000 kg (2210 lbs.)
Lower link end max. loading weight........The max. allowable load which can be put on the lower link end : W0
Implement weight....................................The implement's weight which can be put on the lower link : W1
Max. drawbar load...................................W2
Trailer loading weight .............................The max. loading weight for trailer (without trailer's weight) : W3
To Next Page
