31THREE-POINT HITCH & DRAWBAR
THREE-POINT HITCH & DRAWBAR
(1) Top link
(2) Lifting rod (Left)
(3) Check chains
(4) Turnbuckle
(5) Lower link
(6) Drawbar
(7) Lifting rod (Right)
(8) Top link holder

Table of Contents

Other manuals for Kubota B2320 Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kubota B2320 Series and is the answer not in the manual?

Kubota B2320 Series Specifications

General IconGeneral
Engine TypeDiesel
Engine Power23 hp
TypeCompact Utility Tractor
Fuel TypeDiesel
Engine Cylinders3
Hydraulic SystemOpen Center
3-Point HitchCategory I
Transmission TypeHydrostatic (HST)
Weight1, 433 lbs
Drive4WD
Engine Displacement68.5 cu in
