Kubota L3240 User Manual

4 SPECIFICATIONS
NOTE : *Manufacturer's estimate
The company reserve the right to change the specifications without notice.
Traveling
system
Standard
tire size
Front 7-16 8.3-16 9.5-16
Rear 12.4-24 14.9-24 14.9-26
Clutch Dry type single stage
Steering Hydrostatic power steering
Transmission Hydrostatic transmission (3 speeds)
Braking system Wet disk type
Min. turning radius
(with brake)
m (feet) 2.7 (8.9) 2.8 (9.2)
Hydraulic
unit
Hydraulic control system Position control
Pump capacity
L
(U.S.gals)/
min.
31.5 (8.3) 37.0 (9.8) 35.6 (9.4) 37.0 (9.8)
Three point hitch SAE category 1 SAE category 1, 2
Max. lift
force
At lift
points
kg (lbs.) 1700 (3750) 1750 (3860)
24 in.
behind
lift
points
kg (lbs.) 1200 (2650) 1250 (2760) 1350 (2980)
System pressure
MPa
(kgf/cm )
17.7 (180)
PTO
Rear PTO
SAE 1-3/8, 6 splines
PTO/
Engine
speed
rpm 540/2685 540/2640 540/2590
MID-PTO
(if equipped)
USA No.5 (KUBOTA 10-tooth) involute spline
PTO/
Engine
speed
rpm 2000/2715 2000/2670 2000/2615
Model
L3240 L3540 L3940 L4240 L4740 L5240 L5740
4WD

Kubota L3240 Specifications

General

Engine Type	Diesel
Transmission	Hydrostatic
3-Point Hitch	Category I
Drive	4WD
Cylinders	3
Number of Gears	3 ranges
Hydraulic System Type	Open center
Tire Size (Front)	7-16
Tire Size (Rear)	12.4 - 24
Displacement	91.5 cu in
Transmission Type	Hydrostatic
