Kubota M108S User Manual

7IMPLEMENT LIMITATIONS
A Implement size may vary depending on soil operating conditions.
*1 Must remove front weight with this implement.
*2 Need subframe
No. Implement Remarks M108S
1 Slurry Tank
Max. Tank Capacity L 5000
Max. Load Capacity kg 6000
2 Trailer
Max. Load Capacity kg 7000
Max. Drawbar Load kg 1500
3 Mower
Rotary-Cutter
(3P type)
Max. Cutting Width mm 3200
Max. Weight kg 800
Rotary-Cutter
(Drawbar type)
Max. Cutting Width mm 6096
Disc Mower
(Drawbar type)
Max. Cutting Width mm 3962
Flail Mower
(Heavy)
Max. Cutting Width mm 4267
Max. Weight kg 1360
Sickle Bar Max. Cutting Width mm 3050
4 Sprayer
Max.Tank-
Capacity
Mid L 1000
Rear 3P L 1000
Drawbar L 5500
5 Rotary Tiller
Max. Tilling Width mm 2700
Max. Weight kg 1200
6 Bottom Plow
Max. Size
14 in. x 5
16 in. x 4
18 in. x 4
20 in. x 3
22 in. x 2
24 in. x 1
Max. Weight kg 3P Type 900
7 Disk harrow
3P Type
Max. Size 24 in. x 28
Max. Harrowing Width mm 3300
Max. Weight kg 900
Drawbar Type Max. Harrowing Width mm 4300
8 Disc Plow
Max. Size 28 in. x 4
Max. Weight kg 900
9 Sub Soiler
Numbers of Cultivating Tines 3
Cultivating Depth mm 550
10 Cultivator
Max.Width mm 5490
Number of Rows 6
Max. Weight kg 900
11 Front Blade *1, *2
Max. Cutting Width mm 2600
Max. Oil Pressure MPa (kgf/cm ) 19.6 (200)
12 Rear Blade
Max. Cutting Width mm 2600
Max. Oil Pressure MPa (kgf/cm ) 19.6 (200)
13 Front Loader *1, *2
Max. Lifting Capacity kg 1300
Max. Oil Pressure
(extra hydro kit)
MPa (kgf/cm ) 20.5 (209)
14 Box Blade
Max. Cutting Width mm 2430
Max. Weight kg 800
15 Snow Blade
Max. Width mm 2600
Max. Weight kg 800

Kubota M108S Specifications

General

Engine Power	108 HP
Engine Type	Diesel
PTO Power	92 HP
Engine Model	Kubota V3800
4x4	Yes
Displacement	230 cu in
Hydraulic Remotes	2
3-Point Hitch Category	II
Number of Gears	24 forward and 24 reverse
