Kubota M108S User Manual

63CAB OPERATION
C Defrosting or demisting
To defrost or demist the windshield, take the following
steps.
1. Set the mode switch to the position.
2. Open the front air outlet, door air outlet and direct it to
the windshield.
3. Set the recirculation / fresh air selection lever to the
"FRESH AIR" position.
4. Set the blower switch and the temperature control dial
to the "3" and max "WARM" (end of clockwise)
positions, respectively.
A If you set the temperature control dial to "COOL" side
position at position, cool air will come out from the
face air outlets.
(1) Mode switch
(2) Temperature control dial
(A) "WARM"
(1) Door air outlet (A) "OPEN"
(B) "SHUT"

Kubota M108S Specifications

General

Engine Power	108 HP
Engine Type	Diesel
PTO Power	92 HP
Engine Model	Kubota V3800
4x4	Yes
Displacement	230 cu in
Hydraulic Remotes	2
3-Point Hitch Category	II
Number of Gears	24 forward and 24 reverse
