(1) (2)
SUSPENSION
Standard position: 3
Each shock absorber (1) has 5 adjustment positions for
different load or riding conditions.
Use a pin spanner (2) to adjust the rear shocks. Always
adjust the shock absorber position in sequence (1-2-3-4-5
or 5-4-3-2-1). Attempting to adjust directly from 1 to 5 or 5
to 1 may damage the shock absorber. Position 1 is for
light loads and smooth road conditions. Positions 3 to 5
increase spring preload for a stiffer rear suspension, and
can be used when the scooter is heavily loaded. Be
certain to adjust both shock absorbers to the same
position.
1234 5
3
2
4
5
1
42
