Kyocera ECOSYS P3055dn Service Manual

3NY
1-3-8
1-3-3 Electric problems
Problem Causes Check procedures/corrective measures
(1)Defective paper
jam detecting.
False paper jam
message display.
Actuators of paper feed
sensor does not operate
smoothly.
Check visually and replace if necessary.
A piece of paper torn
from a sheet is caught
around actuator of paper
feed sensor.
Check visually and remove it, if any.
Defective paper feed
sensor.
Replace the paper feed sensor.
Defective PF main PWB. Replace the PF main PWB (See page 1-4-4).
Defective printer’s
engine PWB.
Replace printer’s engine PWB.
(Refer to the service manual for the printer)
(2)Defective paper
gauge sensing.
False paper gauge
indication.
Defective paper gauge
sensors.
Replace the PF main PWB (See page 1-4-4).
Actuator of paper gauge
sensors does not oper-
ate smoothly.
Check visually and replace if necessary.
Defective PF main PWB. Replace PF main PWB (See page 1-4-4).
Defective printer’s
engine PWB.
Replace printer’s engine PWB.
(Refer to the service manual for the printer)
(3)Defective paper
size detecting.
False paper size
message display.
Defective cassette size
switch.
Replace the cassette size switch.
Defective PF main PWB. Replace the PF main PWB (See page 1-4-4).
Defective printer’s
engine PWB.
Replace printer’s engine PWB.
(Refer to the service manual for the printer)

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
