5-2
Operation on the Machine > Loading Paper in the Multipurpose Tray
Loading Paper in the Multipurpose Tray
For details of the supported paper sizes, refer to the following:
Choosing the Appropriate Paper (page 11-13)
For the paper type setting, refer to the following:
Media Type Setting (page 8-12)
Be sure to use the multipurpose tray when you print on any special paper.
The capacity of the multipurpose tray is as follows.
• A4 or smaller plain paper (80 g/m
2
), recycled paper or color paper: 150 sheets
• B4 or larger plain paper (80 g/m
2
), recycled paper or color paper: 50 sheets
• Thick paper (209 g/m
2
): 10 sheets
• Thick paper (157 g/m
2
): 50 sheets
• Thick paper (104.7 g/m
2
): 50 sheets
• Hagaki (Cardstock): 30 sheets
• Envelope DL, Envelope C5, Envelope #10, Envelope #9, Envelope #6 3/4, Envelope Monarch, Youkei 4, Youkei 2:
10 sheets
• OHP film: 10 sheet
• Coated: 10 sheets
• Banner paper: 470.1 mm (18.51") to a maximum of 1220.0 mm (48"): 1 sheet (manual feed), 10 sheets (when
optional banner tray is attached)
• Index tab dividers: 15 sheets
1
Open the multipurpose tray.
• If you are using a paper weight of 106 g/m
2
or more, set the media type to Thick and set the weight of the
paper you are using.
• Remove each transparency from the main tray as it is printed. Leaving transparencies in the main tray may
cause a paper jam.
• When you load custom size paper, enter the paper size by referring to the following:
Paper Settings
(page 8-10)
• When you use special paper such as transparencies or thick paper, select the media type by referring to the
following:
MP Tray Setting
(page 8-7)
• Paper size can be automatically detected and selected, refer to the following:
Paper Selection
(page 6-5)
MP Tray Setting (page 8-7)
To Next Page
