Kyocera FS-1370DN User Manual

2-16 Using the Operation Panel
USB Memory (USB flash memory selection)
This specifies the settings for removing the USB flash memory and
printing USB flash memory content. The USB Memory menu
automatically appears when you install the USB memory.
The options available in USB flash memory are as follows:
• Print File (Printing a file)
• Copies (Number of copies)
• Paper Source (Selecting the paper feed source)
• Remove Device (Removing the USB flash memory)
• Print File List (Printing a list of the files on a USB flash memory)
1 Press [MENU].
2 Press U or V repeatedly until USB Memory > appears.
Note that menus shown in the list may vary depending on which
optional units installed in the printer.
Print File (Printing a file)
You can use this to specify printing for files in the USB flash memory.
1 Press Z while USB Memory > is displayed.
2 >Print File appears. In other displays, press U or V repeatedly
until the map appears.
3 Press [OK]. A question mark (?) appears.
4 Press [OK] again. The folder or file appears.
(For example : Folder 1)
Each time you press U or V, the next folder or file appears in
succession.
To view lower-level folders or files, press Z.
(For example : Folder 2)
To view folders or files on still lower levels, press Z.
(For example : File 3)
You can move between the folder levels by pressing U and V or Y
and Z.
5 Press [OK]. A question mark (?) appears.
(For example : File 3)
6 Press [OK] again. Copies appears.
IMPORTANT This message is displayed only when the USB host
block is set to
Unblock. For more information, refer to Interface
Block (Interface (external device) block setting) on page 2-58.
USB Memory >
IMPORTANT The Print File menu option is only displayed
when there is a PDF, TIFF or XPS file in the USB flash memory.
Note also that up to 3 levels of folders or files are displayed. It
might take some time before the folder or file name appears,
depending on the size of the USB flash memory or the number of
files.
/
/00:Folder 1
/00:Folder 1
/01:Folder 2
/.../01:Folder 2
02:File 3
/.../01:Folder 2
? 02:File 3
Copies
001

Kyocera FS-1370DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR
Memory slots	1
Processor model	440F5
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	11 W
Power consumption (printing)	554 W
Power consumption (PowerSave)	5.5 W
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2800 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Display	LCD
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	267 mm
