Device Settings
1
In Device Settings, select SSD. Or if selected, double-click SSD.
2
In the SSD Settings dialog box, click Add.
3
In the Defined custom boxes list, a new Box number and Box name appear.
If desired, change the number and name in the Box number and Box name
boxes. The number must be within a range of 1 to 1000, and the name length
can be up to 32 characters. You can also type a user name up to 20 characters.
4
Select Shared box to enable the box for multiple users.
Check box selected: All network users can save jobs in the box.
Check box cleared: Only the box owner and network administrator can save
jobs in the box.
5
To require users of a shared box to type a password before printing, select
Require password, and type a password up to 16 characters.
6
Click OK in the SSD Settings and Properties dialog boxes.
The new custom box appears in the Custom Box dialog box when printing.
You can remove a custom box by selecting it in the Defined custom boxes
list and clicking Delete.
You can import a custom box list by clicking Import and browsing for a valid
custom box list file (.CSV or .KXU).
You can save the current custom box list (.CSV or .KXU) in your computer or
network by clicking Export. A saved list can be imported into another printer
driver.
Auto Configure
Auto Configure detects the devices installed on the printing system if it is
connected over a network. Auto Configure can detect printing system devices
such as input devices. When your computer is connected to the printing system
through a TCP/IP or WSD port, the Auto Configure button appears in Device
Settings. Auto Configure updates the Device options list, Memory, and
preview images to keep the printer driver consistent with the printing system
configuration.
Not all installed devices are detected by using Auto Configure. Before
selecting OK in Device Settings, check the settings to make sure that they are
correct.
Note: The default setting for Windows XP Service Pack 2 is for the Windows
Firewall to be set to On. The setting can be changed to allow communication
between the printing system and your computer. In the Windows Security
Alert dialog box, click Unblock.
Silent Auto Configuration
Silent auto configuration checks the printing system every 10 minutes for
changes in optional devices or memory. When a change is detected, the driver
is automatically updated with the new settings. Silent auto configuration is
only available for printing systems installed in Windows 7, Windows Vista, or
Windows Server 2008.
Printer Driver 2-2
