Job
Custom box SSD Optional password When printed from When manually
operation panel deleted or up to 31
days
Quick copy SSD or SD card No When sent from the When printing
computer system is turned off
or storage device is
full
Proof and hold SSD, RAM disk, or No One print when job When printing
SD card is sent; remaining system is turned off
prints later
Private print SSD, RAM disk, or Yes When access code When printing
SD card is entered at system is turned off
operation panel or after printing
Job storage SSD or SD card Optional When printed from When manually
operation panel deleted
Custom Box
Custom Box lets you store print jobs until they are printed from the printing
system's operation panel. You can print one or more jobs from the SSD.
Print jobs can be deleted after printing or saved on the SSD for 1-31 days.
To use custom boxes, each custom box must be set up using the printing
system's operation panel or Command Center RX. They must also be set up in
the SSD Settings dialog box, accessed from Device Settings. The maximum
number of custom boxes is 1000.
Storing a Job in a Custom Box
After custom boxes are assigned, you can send print jobs to custom boxes,
where print jobs are stored on the printing system’s SSD.
1
In the Job tab, select Job storage (e-MPS), then select Custom box.
2
Click Settings.
3
Select a Custom Box Settings option:
Select Use specific box number, and type the box number and password.
Select Prompt for box number, and click OK. When the Custom Box
dialog box appears, type a box number. If a password was set, type the
password.
Select Display box number list, and click OK. When the Custom Box
dialog box appears, select a box from the list. If a password was set, type the
password. This can be selected when Shared box is selected in the SSD
Settings dialog box.
Select Verify box number for each login user, and click OK. When the
Custom Box dialog box appears, type a box number. To include a
password, select Require password and type the password. This can be
selected when Shared box is selected in the SSD Settings dialog box.
With Verify box number for each login user selected, the driver searches for
a login user name from the custom box list to serve as the custom box name:
If a match is found, the custom box is used for the print job.
Printer Driver 8-2
