Kyocera FS-C5150DN Service Manual

2KT/2KV
1-1-1
1-1 Specifi cations
1-1-1 Specifications
Item
Specifications
21/23 ppm model (A4/Letter) 26/28 ppm model (A4/Letter)
Type Desktop
Printing method Electrophotography by semiconductor laser, tandem (4) drum system
Paper weight
Cassette 60 to 163 g/m
2
MP tray 60 to 220 g/m
2
Paper type
Cassette
Plain, Recycled, Preprinted, Bond, Color (Colour), Prepunched,
Letterhead, Thick, High quality, Custom 1 to 8 (Duplex: Same as simplex)
MP tray
Plain, Transparency, Vellum, Labels, Recycled, Preprinted, Bond,
Cardstock, Color (Colour), Prepunched, Letterhead, Thick, Envelope,
Coated, High quality, Custom 1 to 8
Paper size
Cassette
A4, A5, A6, B5, ISO B5, Letter, Legal, Statement, Executive, Oficio II, Folio,
16K, Envelope C5, Custom
MP tray
A4, A5, A6, B5, ISO B5, B6, Letter, Legal, Statement, Executive, Oficio II,
Folio, 16K, Envelope #10, Envelope #9, Envelope #6, Envelope Monarch,
Envelope DL, Envelope C5, Postcards, Return postcard, Youkei 2,
Youkei 4, Custom
Copying
speed
Simplex
A4 : 21 sheets/min
Letter : 23 sheets/min
Legal : 18 sheets/min
B5 : 23 sheets/min
A5 : 23 sheets/min
A6 : 23 sheets/min
A4 : 26 sheets/min
Letter : 28 sheets/min
Legal : 23 sheets/min
B5 : 28 sheets/min
A5 : 28 sheets/min
A6 : 28 sheets/min
Duplex
A4 : 11 sheets/min
Letter : 11 sheets/min
Legal : 10 sheets/min
A4 : 13 sheets/min
Letter : 13 sheets/min
Legal : 12 sheets/min
First print time
(A4, feed from cassette)
B/W : 10.5 s or less
Color: 12.0 s or less
B/W : 9.0 s or less
Color: 10.5 s or less
Warm-up time
(22 °C/71.6 °F, 60% RH)
Power on : 32 s or less
Sleep mode: 18 s or less
Power on : 29 s or less
Sleep mode: 20 s or less
Paper
capacity
Cassette 250 sheets (80g/m
2
) 500 sheets (80g/m
2
)
MP tray 50 sheets (80 g/m
2
) 50 sheets (80 g/m
2
)
Output tray capacity 250 sheets (80g/m
2
)
Photoconductor OPC drum (diameter 30 mm)
Image write system Semiconductor laser
Charging system Charger roller
Developing system
Touch down developing system
Developer: 2-component
Toner replenishing: Automatic from the toner container
Transfer system
Primary: Transfer belt
Secondary: Transfer roller

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
