Operator's Manual – Mega Stacker Lite
© LAI GAMES
Page 11
SOUND, LAMPS & DISPLAY TEST
 ENTER The Sound, Lamp & Display test is entered from Attract mode by
pressing the test button once.
DURING THE TEST:
o Game music and a voice over will be played.
o The Credit display will count from 0000 to 9999 and then repeat.
o The LED Playfield Display panel will run a test pattern sequence.
o The Continue, Start/Stop and Select button lamps will flash on and off
 EXIT The Sound, Lamp & Display test is exited by pressing the test button.
The next test will be the switch test.
SWITCH TEST
 ENTER The Switch Test can be entered by pressing the Test button once while
in the Sound, Light & display test mode or by pressing the Test button
twice while in Attract mode,
C
-
X
X
will be displayed on the 4-digit
display where ‘XX’ is a number representing the switch that is active.
 TESTING THE GAME SWITCHES
All game switches have a code from C1 to C10 as tabled below. By
activating any of the switches, their code will be displayed on the 4-digit
display. If there are no switches are active then
C
-
0
0
will be
displayed.
CODE
DISPLAY
SWITCH FUNCTION
SWITCH LOCATION
C0
C
-
0
0
No Switch Active
-
C1
C
-
0
1
Ticket Notch Active
Ticket Dispenser
C2
C
-
0
2
Service Switch Active
Service Panel
C3
C
-
0
3
Start/Stop Button Active
Control Panel
C4
C
-
0
4
Coin 1 Switch Active
Coin Door
C5
C
-
0
5
Coin 2 Switch Active
Coin Door
C6
C
-
0
6
Payout Button Active
Control Panel
Normal condition for the game is
C
-
0
0
, no switches are active.
* NOTE! *

If there is an active error displayed, press the red test button once to clear the
error.

If the error code will not clear, it can be bypassed quickly by pressing the red
test button twice.
* NOTE! *
 Several switches can be simultaneously activated in the Switch test. The
display will then consecutively show their codes, indicating which switches
are active. However, it is much easier to test the game switches individually.
