* The Bluetooth
®
word mark and the logo are registered trademarks of Bluetooth SIG Inc.
After starting the app and activating the Bluetooth
®
* function, a connection can be set up between
a mobile device and the measuring device. If the app detects several active measuring devices, select
the matching device.
This measuring device can be connected automatically the next time it is switched on.
Make sure that the Bluetooth
®
* interface of the mobile device is activated.
!
An app is required to use the Bluetooth
®
* function.
You can download the app from the corresponding stores for the specic type of terminal device:
Application (app)
Data transfer
The device features a Bluetooth
®
* function that enables wireless data transfer to mobile devices with
a Bluetooth
®
* interface (such as a smartphone or tablet).
The system prerequisites for a Bluetooth
®
* connection are specied at http://laserliner.com/info?an=ble
The device can set up a Bluetooth
®
* connection with Bluetooth 4.0 compatible devices.
The range is set to a maximum distance of 10 m from the terminal device and greatly depends on the
ambient conditions such as the thickness and composition of walls, sources of interference as well as
the transmit / receive properties of the terminal device.
Bluetooth
®
* must be activated after switching on the device as the measuring system or measuring
device is designed for very low power consumption.
A mobile device can link up to the active measuring device via an app.
25
EN
Technical data (Subject to technical alterations. 18W09)
Function Range Resolution
Accuracy
% of measured value (rdg)
+ least significant digits
AC current
50-60 Hz
500.00 A 10 mA
± (2,5% rdg ± 5 digits)
1000.0 A 0.1 A
DC current
500.00 A 10 mA
± (2,5% rdg ± 5 digits)
1000.0 A 0.1 A
AC voltage (Auto range)
500.00 mV 0.01 mV
± (1,0% rdg ± 30 digits)
5.0000 V 0.1 mV
50.000 V 1 mV
500.00 V 10 mV
1000.0 V 0.1 V ± (3,0% rdg ± 8 digits)
