Trouble shooting aids
549263_D_PUB_DATE_7_JUL_2014.DOC INSTALLATION, MAINTENANCE AND USER' MANUAL 53
Trouble shooting aids
Unblocking of the door lock in case of emergency
If the power blackout takes too long, you can make an emergency unblocking of the door lock. The
emergency door opening has been described as follows:
WARNING!
BEFORE THE EMERGENCY DOOR OPENING TURN OFF THE MACHINE MAIN SWITCH!
NEVER OPEN THE DOOR WHILE DRUM IS STILL RUNNING!
NEVER OPEN THE DOOR IF “TOO HOT” IS INDICATED! RISK OF BURN OR SCALD INJURIES!
NEVER OPEN THE DOOR IF THE MACHINE PARTS FEELS TOO WARM!
NEVER OPEN THE DOOR, UNTIL THERE IS NO WATER IN THE DRUM! IN THE OPPOSITE CASE,
IT WILL FLOW OUT AFTER OPENING THE DOOR.
Verify if all condition are present to safely open the door.
Rigid-mount machines: Remove front panel.
Freestanding machines: Gently push the washing unit to back.
Put your fingers over the edge of the front panel on the door lock side.
First push the emergency door opening button, only then turn the door handle right.
Open the door if all safety conditions are fulfilled.
Error indication shown on display
See chapter “First service at technical problem”.
See Programming manual, chapter “Troubleshoting”.
List of recommended spare parts
Find more detailed information and order codes in the spare parts catalogue for individual machines
at your dealer.
o drain valve
o 2-way inlet valve
o 3-way inlet valve
o 4-way inlet valve
o steam valve
o door lock
o fuses
o thermostat sensor
o motor contactor
o heating contactor
o heating element
o belts
o door seal
!
