Technical data
549263_D_PUB_DATE_7_JUL_2014.DOC INSTALLATION, MAINTENANCE AND USER' MANUAL 19
Connections
MACHINE 7 / 15 8 / 18 11 / 25 14 / 30 18 / 40 24 / 55 28 / 65
Water valves
connection BSP DN20 ¾“ DN20 ¾“ DN20 ¾“ DN20 ¾“ DN20 ¾“ DN20 ¾“ DN20 ¾“
Water pressure kPa 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800
Recommended water
pressure kPa 300 - 500 300 - 500 300 - 500 300 - 500 300 - 500 300 - 500 300 - 500
Capacity l/min 20 20 20 20 20 20 20
Drain valve outer ø mm / inch 76 / 3
76 / 3 76 / 3 76 / 3 76 / 3 76 / 3 76 / 3
Flow amount
with drain valve l/min 210 210 210 210 210 210
210
2 x 210
(1)
Drain pump with a hose
internal diameter
of hose mm / inch
flow rate of drain pump l/min
33.5 / 1.32
36
33.5 / 1.32
36
-
-
-
-
-
-
-
-
-
-
Steam valve connection DN15 ½“ DN15 ½“ DN15 ½“ DN15 ½“ DN15 ½“ DN15 ½“ DN15 ½“
Steam pressure kPa 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800 100 - 800
General data
Ambient
temperature °C / °F 5 to 35 / 41 to 95
Relative humidity 30% to 90% without condensation
Height above
sea level m / ft up to 1000 / 3280
Storage
temperature °C / °F 1 to 55 / 34 to 131
Table 3
(1) freestanding machines,( on request)
