Installation
549263_D_PUB_DATE_7_JUL_2014.DOC INSTALLATION, MAINTENANCE AND USER' MANUAL 31
Installation
Freestanding machines
Transportation and unpacking – freestanding machines
The machine is delivered bolted onto the transport pallet and packed in a shrink-wrap foil or box.
o Remove packing from the machine.
o Remove front and rear panel. Remove the bolts between the machine and pallet.
o Mount front and rear panel.
o When the machine is lifted off the pallet: Make sure that the machine does not come down on the floor with
either of the rear corners first. The side panel of the machine can be damaged.
o Mount the feet.
o Level the machine with the feet of the machine.
WARNING!
IT IS OF UTMOST IMPORTANCE THAT THE MACHINE IS PLACED IN LEVEL, FROM SIDE TO SIDE AS
WELL AS FRONT TO REAR. IF THE MACHINE IS NOT PROPERLY LEVELED, IT MAY RESULT IN OUT-
OF-BALANCE WITHOUT A REAL OUT OF BALANCE IN THE DRUM.
Two self-adhesive rubber stop-blocks are supplied with the machine. They might be applied as paint protection
when opening the door.
Recheck the setting of the safety switch, see chapter „Maintenance and adjustments“.
The machine also comes with transport safety devices (four plate angles between the support and the drum).
In order to remove the safety devices:
o Remove front and rear panel, see figure 3., pos.3, 4.
o Remove both front metal transport holders, pos. 1.
o Remove both rear transport holders, pos. 2.
The machine may not be moved with the transport holders removed. Save the transport securities for future
use.
Figure 3 – Freestanding machines
!
