14
PONTOON
LUXURA SHOWN
Cranking Battery
storage area
Fuel Tank Vent
Deep Cycle Battery
storage area
Bow Lights
Bow Docking Lights
& Nav Lights
Trolling motor plug-in
Bilge Pump
Drain Plug
Boarding Ladder
Rear Livewell
Glove Box
In- oor rod storage
Side storage
Front Livewell
Built-In Fuel Tank
Fuel Tank storage area
Battery storage area
Change Room & Sundeck
Fuel Cap
Portable Ladder Anchors
Livewell Drain
Fish/Depth Finder
Gauges
Gauges
Switches:
Circuit Breakers
Navigation Lights
Bilge Pump
Livewell
Horn
Switches:
Circuit Breakers
Navigation Lights
Horn
12 volt outlet
FULL WINDSHIELD 18 XCALIBUR SHOWN
Anchor Light
Under Seat Storage
