LEGRAND DMX3 Series User Manual

113
DMX
3
14. Possible connections for draw-out version
Termination
support must
be made
of isolating
material and
sized according
to the bars in
order to avoid
performances
during
short circuit
conditions.
DMX
3
’s terminals offer more contact area to accept
Aluminium links.
DMX
3
’s Universal Flat terminals greatly facilitate
termination.
These terminals directly support all commonly used
types of termination as shown in adjoining figure.
"X" max (mm)
"X" max (mm)
X
X1
DMX
3
2500 = 25 Nm
DMX
3
4000 = 36 Nm
DMX
3
6300 = 36 Nm
DMX
3
2500 = 25 Nm
DMX
3
4000 = 36 Nm
DMX
3
6300 = 36 Nm
Icc (kA) ≤ 42 ≤ 50 ≤ 65 ≤ 100
“X” max (mm) 350 300 250 150
M8 DMX
3
2500
M10 DMX
3
4000-
6300
(type 8.8)
DMX
3
2500
X max = 16 + 4 + X1
DMX
3
4000-6300
X max = 20 + 5 + X1
DMX
3
2500
= 4mm
DMX
3
4000-6300
= 5mm
DMX
3
2500 = 16mm
DMX
3
4000-6300 = 20mm
