• 46 •
26 26 26 26
35 35 35 35
52 52
52 52 52 52
69 69 69 69
104 104
BALTIC-IOM-0412-E / Service manual
HEATING OPTIONS
Electrical preheater
Pre-heater is running only with high fresh air rate under low outdoor ambient temperature (see setpoint in CLIMATIC™ section).
A metallic fi lter is installed between air fi lter & electrical resistance to protect against heat radiations.
WARNING: electric pre-heater is connected heater to mainS power – risk of electrical Shock – switch off the
unit prior to open this section
WARNING: electric pre-heater metallic fi lter must not be plugged by dust
Amps per model
size
C BOX D BOX E BOX
24 30 38 42 45 52 57 65 75 85
Size S / H
S 18 kW
S 24 kW
S 36 kW
H 36 kW
H 48 kW
H 72 kW
