CBX32MV
Specifications
General Data Model Number CBX32MV‐018/024 CBX32MV‐024/030 CBX32MV‐036
Nominal cooling capacity - tons (kW) 1.5 - 2 (5.3 - 7) 2 - 2.5 (7 - 8.8) 3 (10.6)
Refrigerant R-410A R-410A R-410A
Connections
in. (mm)
Suction (vapor) line - sweat 5/8 (15.8) 3/4 (19) 3/4 (19)
Liquid line - sweat 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Condensate drain (fpt) (2) 3/4 (19) (2) 3/4 (19) (2) 3/4 (19)
Indoor Coil
Net face area - ft.
2
(m
2
) 3.56 (0.33) 4.44 (0.41) 5.0 (0.46)
Tube outside diameter - in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Number of rows 3 3 3
Fins per inch (fins per m) 12 (472) 12 (472) 12 (472)
Blower Data
Wheel nominal diameter x width - in. (mm) 10 x 7 (279 x 178) 10 x 8 (279 x 203) 10 x 8 (279 x 203)
Motor output - hp (W) 1/2 (373) 1/2 (373) 1/2 (373)
Filters
1
Number and size - in. (1) 15 x 20 x 1 (1) 20 x 20 x 1 (1) 20 x 20 x 1
mm 381 x 508 x 25 508 x 508 x 25 508 x 508 x 25
Shipping Data - 1 Package lbs. (kg) 126 (57) 152 (69) 183 (83)
ELECTRICAL DATA
Voltage - phase - 60hz 208/230V-1ph
208/230V-1ph 208/230V-1ph
Maximum overcurrent protection (unit only)
2
15 15 15
Minimum circuit ampacity (unit only) 5 5 5
General Data Model Number CBX32MV‐048 CBX32MV‐060 CBX32MV‐068
Nominal cooling capacity - tons (kW) 4 (14.1) 5 (17.6) 5+ (17.6+)
Refrigerant HFC-410A HFC-410A HFC-410A
Connections
in. (mm)
Suction (vapor) line - sweat 7/8 (22.2) 1‐1/8 (28) 1‐1/8 (28)
Liquid line - sweat 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Condensate drain (fpt) (2) 3/4 (19) (2) 3/4 (19) (2) 3/4 (19)
Indoor Coil
Net face area - ft.
2
(m
2
) 7.22 (0.67) 7.22 (0.67) 7.77 (0.72)
Tube outside diameter - in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
Number of rows 3 3 3
Fins per inch (fins per m) 12 (472) 12 (472) 12 (472)
Blower Data
Wheel nominal diameter x width - in. (mm) 12 x 9 (305 x 229) 12 x 9 (305 x 229) 15 x 9 (381 x 229)
Motor output - hp (W) 1 (746) 1 (746) 1 (746)
Filters
1
Number and size - in. (1) 20 x 24 x 1 (1) 20 x 24 x 1 (1) 20 x 25 x 1
mm 508 x 610 x 25 508 x 610 x 25 508 x 635 x 25
Shipping Data - 1 Package - lbs. (kg) 212 (96) 212 (96) 244 (111)
ELECTRICAL DATA
Voltage - phase - 60hz 208/230V-1ph
208/230V-1ph 208/230V-1ph
Maximum overcurrent protection (unit only)
2
20 20 20
Minimum circuit ampacity (unit only) 11 11 11
