Lennox CBX32MV-036 User Manual

Page 48
CBX32MV
Table 13. Cooling Operation and Jumper Summary
CBX32MV COOLING OPERATION AND JUMPER SUMMARY (OPTIONAL ACCESSORIES) WITHOUT
ComfortSense
®
7000t WITHOUT HARMONY IIIt
UNIT JUMPERS
THERMOSTAT
DEMAND
BLOWER SPEED
Single Speed Condensing Unit
DS to R
Y1 to Y2
O to R
Y1 COOL
Two Speed Condensing Unit
DS to R
O to R
Y1 70% of COOL
Y2 COOL
Single Speed Heat Pump
DS to Y1
Y1 to Y2
Y1 COOL
Two Speed Heat Pump DS to R
Y1 70% of COOL
Y2 COOL
CBX32MV COOLING OPERATION AND JUMPER SUMMARY (OPTIONAL ACCESSORIES)
WITH ComfortSense 7000 WITHOUT HARMONY III
UNIT JUMPERS THERMOSTAT DEMAND and BLOWER SPEED
Single Speed Condensing Unit
Y1 to Y2
O to R
See table 14
Two Speed Condensing Unit O to R See table 15
Single Speed Heat Pump Y1 to Y2 See table 14
Two Speed Heat Pump NONE See table 15
CBX32MV COOLING OPERATION AND JUMPER SUMMARY (OPTIONAL ACCESSORIES)
WITHOUT ComfortSense 7000 WITH HARMONY III
UNIT JUMPERS SEQUENCE OF OPERATION
Single or Two Speed Condensing Unit O to R
Harmony controls blower speed according to size of demand,
through pulse width modulated signal to DS
Single or Two Speed Heat Pump NONE
Harmony controls blower speed according to size of demand,
through pulse width modulated signal to DS
NOTE - Continuous fan CFM will be 50% of COOL speed. Blower will run on HEAT speed during Heat operation.
