- 11 -
4. HD Display
4.1. Wi-Fi
4.1.1. Router and Internet Connection:
This is for connecting the S30 Control System to the home wireless network. This settings is disabled by de
fault.
D. From the home screen, go to menu > settings > wi-fi
E. Slide the option to ON to enable Wi-Fi.
If the Access Point is Visible
A. Wi-Fi network will show not connected. Press on not connected.
B. Select a network will be displayed listing all detected networks within range. Selected your home network
by pressing on the network name. DO NOT USE A GUEST OR UNSECURE ACCESS POINT.
C. Assuming that your network is secure, a password will be requested. Enter your password and press join
to continue.
NOTE - If you wish to see the characters you are typing, check show password.
Access Point is Hidden
A. Slide the option to ON to enable Wi-Fi.
B. Wi-Fi network will show not connected. Press on not connected.
C. Select other.
D. The enter new network information screen will appear. Enter the name of the hidden network.
E. Select Security. Options are none, WEP, WPA and WPA2. DO NOT USE A GUEST OR UNSECURE
ACCESS POINT.
F. Once security type is selected, a password field will appear. Enter the password and press join to contin
ue..
NOTE - If you wish to see the characters you are typing, check show password.
Whether connecting to a visible or hidden network, if successful, the connection icon above both the router
and Internet icon will have a green check mark above each.
✔
✔
4.1.2. Consumer Account Creation from Thermostat and Connection to Server
Reasons to create an account:
S To enable remote access to the system using a mobile device with the Lennox mobile application installed
while away from home. This will allow remote adjustment for temperature settings and other features.
S To enable the Smart Away feature discussed later on in this instruction.
