BLOWER DATA - DIRECT DRIVE - KGB030
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (larger gas heat section, economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS
High Medium Low High Medium Low
2.5 Ton Standard Efciency (Downow) KGB030S
0.0 1211 949 852 1365 1097 916
0.1 1251 946 826 1422 1099 908
0.2 1241 952 794 1419 1112 893
0.3 1234 915 749 1419 1074 861
0.4 1213 880 702 1402 1038 824
0.5 1178 846 661 1366 1003 795
0.6 1118 790 585 1302 942 720
0.7 1054 751 518 1231 900 655
0.8 964 675 460 1130 815 600
0.9 882 626 368 1037 762 501
1.0 729 494 286 859 606 412
2.5 Ton Standard Efciency (Horizontal) KGB030S
0.0 1163 930 815 1312 1075 875
0.1 1173 912 783 1333 1060 861
0.2 1169 888 746 1337 1037 839
0.3 1152 858 704 1325 1007 809
0.4 1122 822 657 1297 969 772
0.5 1079 779 606 1252 923 728
0.6 1023 730 549 1191 870 676
0.7 953 674 488 1114 808 617
0.8 871 613 422 1020 739 550
0.9 775 545 350 911 662 476
1.0 666 470 274 785 578 395
