Page 28
BLOWER DATA - DIRECT DRIVE - KCB024
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (economizer, wet coil, etc.) See page 41 .
2 - Any eld installed accessories air resistance (electric heat, duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS
High Medium Low High Medium Low
2 Ton Standard Efciency (Downow) KCB024S
0.0 1244 956 859 1414 1098 876
0.1 1226 934 820 1401 1092 870
0.2 1201 906 782 1379 1070 848
0.3 1180 877 727 1348 1039 819
0.4 1152 841 690 1318 1008 775
0.5 1118 812 634 1288 968 746
0.6 1090 768 579 1243 937 702
0.7 1048 725 505 1197 890 659
0.8 1006 667 431 1152 827 600
0.9 950 609 357 1076 749 528
1.0 839 493 248 986 623 468
2 Ton Standard Efciency (Horizontal) KCB024S
0.0 1166 910 801 1376 1071 842
0.1 1156 893 770 1342 1054 826
0.2 1136 866 734 1307 1021 808
0.3 1115 826 697 1269 982 771
0.4 1083 800 643 1232 956 734
0.5 1051 747 589 1194 903 698
0.6 1009 707 534 1137 850 662
0.7 946 668 467 1100 797 588
0.8 861 588 396 1024 744 534
0.9 736 508 319 948 652 466
1.0 560 385 237 845 549 392
