Lennox KCA048 User Manual

Page 35
BLOWER DATA - BELT DRIVE - KCA060
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (electric heat, duct resistance, diffuser, etc.) See page 41.
See page 41 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
cfm
External Static - in. w.g.
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Field Furnished Drive Kit A03
1600 738 0.32 785 0.36 831 0.41 878 0.45 923 0.49 969 0.53 1014 0.57 1061 0.59
1700 773 0.36 816 0.41 859 0.46 903 0.51 947 0.55 991 0.58 1036 0.62 1082 0.65
1800 803 0.42 844 0.47 886 0.52 929 0.57 972 0.61 1016 0.64 1060 0.68 1106 0.71
1900 831 0.48 872 0.54 915 0.59 957 0.63 1000 0.67 1043 0.71 1087 0.74 1131 0.78
2000 861 0.56 903 0.61 945 0.66 988 0.70 1030 0.74 1072 0.77 1115 0.81 1157 0.85
2100 893 0.63 935 0.69 978 0.73 1019 0.78 1060 0.81 1101 0.85 1143 0.89 1182 0.93
2200 927 0.71 969 0.76 1011 0.81 1052 0.85 1091 0.89 1131 0.93 1170 0.97 1206 1.02
2300 963 0.79 1004 0.84 1045 0.89 1084 0.93 1122 0.97 1159 1.02 1195 1.07 1228 1.13
2400 999 0.88 1039 0.92 1078 0.97 1115 1.02 1151 1.06 1186 1.12 1219 1.18 1250 1.24
Air
Volume
cfm
External Static - in. w.g.
0.90 1.00 1.10 1.20 1.30 1.40 1.50 1.60
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Drive Kit A03 Drive Kit A07
1600 1107 0.62 1151 0.66 1190 0.70 1228 0.74 1264 0.78 1298 0.82 1332 0.86 1364 0.90
1700 1128 0.68 1169 0.72 1206 0.76 1242 0.80 1277 0.84 1310 0.88 1343 0.92 1375 0.96
1800 1150 0.74 1189 0.79 1223 0.83 1257 0.87 1291 0.91 1324 0.95 1356 0.99 1388 1.03
1900 1173 0.81 1208 0.86 1240 0.91 1273 0.95 1306 0.99 1338 1.03 1369 1.07 1401 1.12
2000 1195 0.89 1228 0.94 1257 0.99 1290 1.04 1321 1.08 1353 1.12 1384 1.16 1416 1.20
2100 1217 0.98 1247 1.04 1275 1.09 1306 1.14 1338 1.18 1369 1.22 1400 1.25 1432 1.29
2200 1238 1.08 1265 1.14 1293 1.19 1324 1.24 1355 1.28 1387 1.31 1418 1.35 1450 1.39
2300 1257 1.19 1284 1.25 1313 1.30 1344 1.34 1375 1.38 1406 1.41 1437 1.45 1470 1.48
2400 1278 1.30 1305 1.36 1334 1.40 1364 1.44 1395 1.48 1427 1.51 1458 1.55 1492 1.58
HORIZONTAL
Air
Volume
cfm
External Static - in. w.g.
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80
RPM BHP RPM BHP RPM BHP RPM BHP RPM
BHP RPM BHP RPM BHP RPM BHP
Field Furnished Drive
Kit A03
1600 752 0.30 798 0.35 844 0.40 889 0.45 933 0.49 975 0.53 1018 0.57 1062 0.60
1700 785 0.35 827 0.40 871 0.46 914 0.51 957 0.55 999 0.59 1042 0.63 1085 0.66
1800 813 0.42 855 0.47 898 0.52 940 0.57 983 0.62 1025 0.66 1067 0.69 1110 0.72
1900 841 0.49 883 0.54 926 0.60 969 0.65 1011 0.69 1052 0.72 1094 0.76 1136 0.79
2000 871 0.56 914 0.62 957 0.67 1000 0.72 1040 0.76 1081 0.79 1122 0.83 1162 0.87
2100 903 0.64 946 0.70 990 0.75 1031 0.79 1071 0.83 1110 0.87 1150 0.91 1189 0.96
2200 937 0.73 981 0.78 1023 0.83 1063 0.87 1102 0.91 1140 0.96 1178 1.01 1215 1.07
2300 973 0.81 1015 0.86 1056 0.91 1095 0.96 1132 1.01 1170 1.06 1206 1.12 1242 1.19
2400 1010 0.91 1051 0.96 1090 1.01 1127 1.06 1164 1.11 1200 1.18 1235 1.24 1269 1.31
Air
Volume
cfm
External Static - in. w.g.
0.90 1.00 1.10 1.20 1.30 1.40 1.50 1.60
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Drive Kit A03 Drive Kit A07
1600 1107 0.63 1149 0.67 1187 0.71 1223 0.75 1258 0.79 1291 0.83 1323 0.87 1354 0.91
1700 1129 0.69 1169 0.73 1204 0.78 1240 0.82 1274 0.86 1306 0.90 1338 0.95 1369 0.99
1800 1152 0.76 1190 0.80 1223 0.85 1258 0.90 1291 0.94 1323 0.99 1354 1.03 1385 1.07
1900 1176 0.83 1212 0.89 1243 0.94 1277 0.99 1309 1.03 1341 1.08 1372 1.12 1402 1.16
2000 1201 0.92 1234 0.98 1264 1.04 1296 1.09 1329 1.13 1360 1.18 1391 1.22 1422 1.26
2100 1225 1.02 1256 1.08 1285 1.14 1318 1.19 1349 1.24 1381 1.28 1412 1.32 1442 1.36
2200 1249 1.13 1279 1.19 1308 1.25 1340 1.30 1372 1.34 1403 1.38 1434 1.42 1465 1.46
2300 1273 1.25 1303 1.31 1332 1.36 1364 1.41 1396 1.45 1427 1.49 1458 1.53 1490 1.57
2400 1300 1.37 1329 1.43 1359 1.47 1390 1.52 1422 1.56 1453 1.60 1484 1.64 1516 1.67
