SPECIFICATIONS MSAV MODELS
General Data Nominal Tonnage 7.5 Ton 8.5 Ton 10 Ton 12.5 Ton
High High High High
Model Number LGT092H4E LGT102H4E LGT120H4E LGT150H4E
Blower Type DirectPlus™
ECM Direct Drive
with MSAV
®
DirectPlus™
ECM Direct Drive
with MSAV
®
DirectPlus™
ECM Direct Drive
with MSAV
®
DirectPlus™
ECM Direct Drive
with MSAV
®
Cooling
Performance
Gross Cooling Capacity - Btuh
1
Net Cooling Capacity - Btuh
1
Total Unit Power - kW 8.1
1
IEER (Btuh/Watt) 14.6
1
EER (Btuh/Watt) 12.3 12.1 12.1
Refrigerant
Charge
Refrigerant Type
Without Reheat
Option
Circuit 1
Circuit 2
With Reheat
Option
Circuit 1
Circuit 2
Gas Heating Options Available
Compressor Type (number) Two-Stage Scroll (1)
Single-Stage Scroll (1)
Outdoor Coils Net face area (total) - sq. ft.
Number of rows 1 1 1 1
23 23 23 23
Outdoor
Coil Fans
2 (1/3) 2 (1/3) 2 (1/2) 2 (1/2)
Motor rpm
Total Motor watts
Diameter - (No.) in. (2) 24 (2) 24 (2) 24 (2) 24
Number of blades 3 3 3 3
Total Air volume - cfm
Indoor
Coil
Net face area (total) - sq. ft.
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 4 4 4 4
14 14 14 14
Drain connection - Number and size (1) 1 in. NPT coupling
Expansion device type Balanced Port Thermostatic Expansion Valve
(removable element head)
Indoor
Blower
Nominal motor output
Blower wheel nominal diameter x width - in. (1) 22 x 9 (1) 22 x 9 (1) 22 x 9 (1) 22 x 9
Filters
Number and size - in.
Electrical characteristics
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1
