39
Step 6. Removethescrewsontherearcoilguardand
thenremovethecoilguard.
Front Cover
Step 7. Removethescrewsfromtherightpanelandthen
removepanel.
Right Panel
18.2.2. Panel Plate (MWCA024S4)
Step 1. Turnofftheairconditionerandthepower
breaker.
Step 2. Removethescrewsthatsecurethehandleand
thenremovethehandle.
Step 3. Removethescrewsfromthetopcoverandthen
remove.Oneofthescrewsislocatedunderneath
thehandle.
Top Cover
Step 4. Removethescrewsfromthefrontpanelandthen
removepanel.
Front Panel
