Lennox Mini-Split Service Manual / Page 211

EE Flow Chart

Power off, then restart the unit 3 minutes

later. Is it still displaying the error code?

If the water-level switch is inserted well?

Yes

Insert the water-level

switch well.

If the water-level switch is broken?

Replace the water pump, If malfunction is

still not solved.

Replace the indoor main PCB.

Yes

Replace the water-level

switch.
