MULTI-ZONE SYSTEM COMBINATIONS
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPA048S4M
4
009 009 009 009 - - - 9,049 9,049 9,049 9,049 - - - 9,595 9,595 9,595 9,595 - - -
009 009 009 012 - - - 8,971 8,971 8,971 11,857 - - - 9,470 9,470 9,470 12,725 - - -
009 009 009 018 - - - 8,883 8,883 8,883 16,875 - - - 9,385 9,385 9,355 17,760 - - -
009 009 009 024 - - - 8,521 8,521 8,521 21,673 - - - 9,155 9,155 9,055 22,755 - - -
009 009 012 012 - - - 8,922 8,922 11,678 11,678 - - - 9,360 9,360 12,280 12,280 - - -
009 009 012 018 - - - 8,865 8,865 11,566 16,469 - - - 9,340 9,340 12,123 17,435 - - -
009 009 012 024 - - - 8,447 8,447 10,888 21,554 - - - 9,140 9,140 11,550 21,675 - - -
009 009 018 018 - - - 8,491 8,491 16,484 16,484 - - - 9,175 9,175 16,535 16,535 - - -
009 009 018 024 - - - 8,252 8,252 15,295 20,113 - - - 9,050 9,050 15,765 21,520 - - -
009 012 012 012 - - - 8,813 11,584 11,584 11,584 - - - 9,330 12,141 12,141 12,141 - - -
009 012 012 018 - - - 8,534 11,256 11,256 16,381 - - - 9,185 12,010 12,010 17,442 - - -
009 012 012 024 - - - 8,354 10,502 10,502 21,165 - - - 9,150 9,150 12,165 21,545 - - -
009 012 018 018 - - - 8,398 10,643 16,371 16,371 - - - 9,155 11,650 16,465 16,465 - - -
012 012 012 012 - - - 11,381 11,381 11,381 11,381 - - - 12,035 12,035 12,035 12,035 - - -
012 012 012 018 - - - 10,697 10,697 10,697 16,611 - - - 11,755 11,755 11,755 16,550 - - -
012 012 012 024 - - - 10,130 10,130 10,130 20,666 - - - 11,210 11,210 11,210 20,155 - - -
012 012 018 018 - - - 10,115 10,115 15,774 15,774 - - - 11,240 11,240 16,235 16,235 - - -
5
009 009 009 009 009 9,000 9,000 9,000 9,000 9,000 9,800 9,800 9,800 9,800 9,800
009 009 009 009 012 8,814 8,814 8,814 8,814 11,729 9,534 9,534 9,534 9,534 12,862
009 009 009 009 018 8,672 8,672 8,672 8,672 16,753 9,355 9,355 9,355 9,355 16,825
009 009 009 009 024 8,295 8,295 8,295 8,295 19,032 9,095 9,095 9,095 9,095 19,535
009 009 009 012 012 8,687 8,687 8,687 11,079 11,079 9,305 9,305 9,335 12,325 12,325
009 009 009 012 018 8,486 8,486 8,486 10,849 15,598 9,105 9,105 9,105 12,025 16,325
009 009 012 012 012 8,501 8,501 11,387 11,387 11,387 9,213 9,213 11,870 11,870 11,870
009 009 012 012 018 8,457 8,457 10,815 10,815 14,253 8,933 8,933 10,967 10,967 15,870
009 012 012 012 012 8,550 10,414 10,414 10,414 10,414 8,525 11,525 11,525 11,525 11,525
012 012 012 012 012 10,306 10,306 10,306 10,306 10,306 11,055 11,055 11,055 11,055 11,055
1
One outdoor unit may be matched with one indoor unit for single zone applications. A second indoor unit can be added at a later date for multi-zone applications.
