Lennox XC21 Engineering Data

XC21 - 2 to 5 Ton Air Conditioner / Page 14
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC21-024-230 TXV 25,600 20.20 14.50 C33-36 SL280UH070XV36A 4261013
XC21-024-230 TXV 26,000 20.20 14.70 C33-36 SL280UH090V36B 4261050
XC21-024-230 TXV 25,200 19.20 14.20 C33-36 SL280UH090V48B 4261024
XC21-024-230 TXV 25,600 20.00 14.50 C33-36 SLP98UH070V36B 4261011
XC21-024-230 TXV 25,600 20.20 14.50 C33-36 SLP98UH090V36C 4261012
XC21-024-230 TXV 24,800 16.70 12.70 C33-36 4260813
XC21-024-230 TXV 26,400 20.20 14.70 C33-38 G61MPV-36B-045 4261027
XC21-024-230 TXV 26,200 20.50 14.70 C33-38 G61MPV-36B-070 4261028
XC21-024-230 TXV 26,400 20.50 14.70 C33-38 G61MPV-36B-071 4261029
XC21-024-230 TXV 26,000 20.20 14.20 C33-38 O23V2/3-70/90 4261030
XC21-024-230 TXV 26,400 20.70 15.00 C33-38 SL280UH070V36A 4261025
XC21-024-230 TXV 26,400 20.70 15.00 C33-38 SL280UH070XV36A 4261032
XC21-024-230 TXV 26,800 20.70 15.00 C33-38 SL280UH090V36B 4261026
XC21-024-230 TXV 26,000 20.00 14.50 C33-38 SL280UH090V48B 4261015
XC21-024-230 TXV 26,400 20.50 15.00 C33-38 SLP98UH070V36B 4261031
XC21-024-230 TXV 25,600 17.20 13.20 C33-38 4260811
XC21-024-230 TXV 25,600 19.70 14.20 C33-42 G61MPV-36B-045 4261017
XC21-024-230 TXV 25,400 20.00 14.20 C33-42 G61MPV-36B-070 4261018
XC21-024-230 TXV 25,600 20.00 14.20 C33-42 G61MPV-36B-071 4261019
XC21-024-230 TXV 25,200 19.70 13.70 C33-42 O23V2/3-70/90 4261020
XC21-024-230 TXV 26,000 20.20 14.70 C33-42 SL280UH090V36B 4261016
XC21-024-230 TXV 25,200 19.20 14.20 C33-42 SL280UH090V48B 4261022
XC21-024-230 TXV 25,600 20.00 14.50 C33-42 SLP98UH070V36B 4261021
XC21-024-230 TXV 24,800 16.70 12.70 C33-42 4260810
XC21-024-230 TXV 25,800 19.50 14.70 CBX27UH-024 4260915
XC21-024-230 TXV 26,000 20.70 15.00 CBX27UH-030 4260916
XC21-024-230 TXV 24,800 17.00 13.00 CBX32M-018/024 4260906
XC21-024-230 TXV 25,400 17.70 13.50 CBX32M-030 4260907
XC21-024-230 TXV 25,400 17.50 13.50 CBX32M-036 4260908
XC21-024-230 TXV 25,400 19.00 14.00 CBX32MV-018/024 4260909
XC21-024-230 TXV 25,800 19.50 14.50 CBX32MV-024/030 4260910
XC21-024-230 TXV 26,400 21.00 14.70 CBX32MV-036 4260911
XC21-024-230 TXV 26,000 20.50 14.70 CBX40UHV-024 4260912
XC21-024-230 TXV 26,000 20.20 14.70 CBX40UHV-030 4260913
XC21-024-230 TXV 26,800 20.70 15.20 CBX40UHV-036 4260914
XC21-024-230 TXV 23,800 18.20 13.50 CH23-21 G61MPV-36B-045 4260859
XC21-024-230 TXV 23,800 18.50 13.50 CH23-21 G61MPV-36B-070 4260860
XC21-024-230 TXV 23,800 18.50 13.50 CH23-21 G61MPV-36B-071 4260861
XC21-024-230 TXV 23,800 18.70 13.50 CH23-21 SL280UH070V36A 4260858
XC21-024-230 TXV 23,800 18.70 13.50 CH23-21 SL280UH070XV36A 4260954
XC21-024-230 TXV 23,600 18.00 13.20 CH23-21 SL280UH090V48B 4260975
XC21-024-230 TXV 23,800 18.50 13.50 CH23-21 SLP98UH070V36B 4260935
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.
