Lenovo 14IAP7 User Manual

Figure 10. Remove antenna conductive fabric and shield conductive fabric
Step 2. Loosen six screws and remove two screws then remove the heat sink.
Figure 11. Remove the heat sink
Screw specifications
Number of screws
2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Antenna conductive fabric
Shield conductive fabric
Heat sink
Remove the fans
Make sure the following FRUs (or CRUs) have been removed.
“Remove the rubber foot” on page 28
“Remove the lower case” on page 29
“Remove the heat sink” on page 32
Chapter 4. Removing a FRU or CRU 33

Lenovo 14IAP7 Specifications

General

Display	14-inch, 1920 x 1080 (FHD)
Storage	256GB SSD
Operating System	Windows 11 Home
Graphics	Intel UHD Graphics
Wireless	Wi-Fi 6
Camera	720p HD
Audio	Stereo speakers, Dolby Audio
Dimensions	324 x 215 mm
Ports	1 x USB 3.2 Gen 1, 1 x USB-C, 1 x HDMI, 1 x headphone/mic combo, 1 x SD card reader
