Figure 22. Remove the touchpad

Screw specifications Number of screws

M1.6 x 2 4

Go to

https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following

replacement part:

Touchpad

Remove the fingerprint sensor and sensor bracket

Make sure the following FRUs (or CRUs) have been removed.

“Remove the lower case” on page 30

“Remove the battery pack” on page 31

Step 1. Remove one screw. Then, remove the fingerprint sensor bracket.

Figure 23. Remove the fingerprint sensor bracket

42 Yoga 6 (13″, 05) Hardware Maintenance Manual
