Lenovo Yoga 6 Hardware Maintenance Manual

Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Microphone rubbers
Remove the sensor board and cable
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 30
“Remove the upper case assembly” on page 47
“Remove the stripe cover” on page 49
“Remove the LCD panel” on page 50
Step 1. Disconnect the sensor board cable from the LCD panel.
Figure 40. Disconnect the sensor board cable
Step 2. Remove the sensor board from the LCD panel.
56
Yoga 6 (13″, 05) Hardware Maintenance Manual

Lenovo Yoga 6 Specifications

General

Operating System	Windows 11 Home
Processor	AMD Ryzen 7 5700U
Display	13.3-inch FHD (1920 x 1080) IPS, touchscreen
Storage	512GB SSD
Graphics	AMD Radeon Graphics
Battery Life	Up to 18 hours
Audio	2 x 2W speakers
Connectivity	Wi-Fi 6 (802.11ax), Bluetooth 5.0
Ports	1 x Headphone / mic combo
Color	Abyss Blue
