Technical data
Weights
3

11
BA 12.0028−EN 6.0
3.2 Weights
Weights [kg]: Helical gearboxes / helical−geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
071 080 090 100 112 132 160 180 200 225
12.61.08 < 11 < 14 −−− −−− −−− −−− −−− −−− −−− −−− < 4.5
12.62.08 < 12 < 15 −−− −−− −−− −−− −−− −−− −−− −−− < 6
12.61.10 < 13 < 16 < 20 < 25 −−− −−− −−− −−− −−− −−− < 6.5
12.62.10 < 15 < 18 < 25 −−− −−− −−− −−− −−− −−− −−− < 9
12.63.10 < 18 < 20 −−− −−− −−− −−− −−− −−− −−− −−− < 12
12.61.12 < 18 < 20 < 25 < 30 < 35 −−− −−− −−− −−− −−− < 12
12.62.12 < 25 < 25 < 35 < 40 −−− −−− −−− −−− −−− −−− < 17
12.63.12 < 25 < 30 < 35 −−− −−− −−− −−− −−− −−− −−− < 20
12.61.16 −−− < 30 < 40 < 45 < 50 < 90 −−− −−− −−− −−− < 20
12.62.16 −−− < 40 < 50 < 55 < 60 < 100 −−− −−− −−− −−− < 35
12.63.16 < 45 < 50 < 55 < 60 −−− −−− −−− −−− −−− −−− < 40
12.61.20 −−− −−− < 55 < 60 < 70 < 105 < 170 −−− −−− −−− < 40
12.62.20 −−− −−− < 80 < 85 < 90 < 130 < 190 −−− −−− −−− < 60
12.63.20 −−− < 80 < 90 < 95 < 100 < 140 −−− −−− −−− −−− < 75
12.61.25 −−− −−− −−− < 75 < 85 < 120 < 185 < 240 −−− −−− < 65
12.62.25 −−− −−− −−− < 130 < 135 < 175 < 240 < 295 −−− −−− < 115
12.63.25 −−− −−− < 140 < 150 < 155 < 195 < 255 −−− −−− −−− < 130
12.61.32 −−− −−− −−− −−− −−− < 135 < 205 < 260 < 340 < 445 < 85
12.62.32 −−− −−− −−− −−− −−− < 250 < 315 < 370 < 450 < 455 < 200
12.63.32 −−− −−− −−− < 240 < 245 < 285 < 350 < 405 −−− −−− < 225
Weights [kg]: Worm gearboxes / worm−geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
063 071 080 090 100 112 132
52..04 < 13 < 15 < 18 −−− −−− −−− −−− < 6.5
52..05 −−− < 20 < 25 −−− −−− −−− −−− < 15
52..06 −−− −−− < 35 < 45 −−− −−− −−− < 20
52..08 −−− −−− < 50 < 60 < 65 < 80 −−− < 35
52..10 −−− −−− −−− < 75 < 80 < 95 −−− < 50
52..12 −−− −−− −−− −−− < 125 < 140 < 170 < 85
