Maintenance
Maintenance operations
Replacing the lubricant
7
21
BA 12.0028−EN 6.0
7.2 Maintenance operations
7.2.1 Replacing the lubricant
ƒ Gearbox should be warm.
ƒ Secure drive system and machine from inadvertent movement and mains
connection.
Stop!
The input stage is separately greased − completely drain all gearbox parts!
1. Drain lubricant through orifice.
2. Insert oil drain plug with new seal.
3. Fill up lubricant through filler.
4. Insert filling screw.
5. Dispose of waste oil according to the applicable regulations.
7.2.2 Lubricant quantity
Single−stage helical gearboxes / geared motors
Lubricant quantity [l]: Single−stage helical gearboxes / geared motors
Gearbox type Design
B3, B3/B11, B3/B5, B5, B6, B7, B8, B10,B14 V1, V1/V5, V3, V5, V6, V3/V6, V10, V14, V18,
V19
12.61.08 0.12 0.12
12.61.10 0.22 0.22
12.61.12 0.40 0.40
12.61.16 0.80 0.80
12.61.20 1.60 1.60
12.61.25 3.50 3.50
12.61.32 7.50 7.50
