15
l
If the cable between RFI filter and controller is longer than 200 mm, use
screened mains cables. The ground chassis connection should have as low a
resistance and as large a surface as possible.
Type 53x can be used for operation with armature voltage or tacho feedback
(see chapter 4.5 "Connecting diagram").
In case of armature voltage control with "I x R compensation" insert a jumper
between terminal 2 and terminal 4.
Caution!
At terminals 2/4 and 3/4 only the feedback system used must be
connected.
For master voltage operation remove the set-value potentiometer and apply the
master voltage across terminal 7 (-) and terminal 8 (+).
Caution!
The master voltage must be free of mains and ground potential. Several
controllers can only be operated from a master voltage when they are
electrically isolated.
Note for the connection of controller and motor
Lenze controller Motor (acc. to DIN 42017 / VDE 0530 part 8)
Function Terminal Terminal other
designations
Motor type
Armature voltage +
-
Excitation voltage +
-
A
B
I
K
1B1
2B2
F1
F2
A1
B2, A2
E1
E2
DC motor uncompensated
with commutating pole
winding
Armature voltage +
-
Excitation voltage +
-
A
B
I
K
1C1
C2
F1
F2
A1
C2
E1
E2
DC motor compensated
with commutating pole
winding
Armature voltage +
-
A
B
A1
A2
Permanent magnet motor
DC tacho +
-
3
4
2A1
2A2
AC tacho +
with rectification -
3
4
3A1
3A2
