DIP switch positions for setting the CAN node address
102 Lenze · Decentralised frequency inverter 8400 motec (CANopen option) · EDS84DMOTCAN EN 4.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
39 OFF ON OFF OFF ON ON ON
40 OFF ON OFF ON OFF OFF OFF
41 OFF ON OFF ON OFF OFF ON
42 OFF ON OFF ON OFF ON OFF
43 OFF ON OFF ON OFF ON ON
44 OFF ON OFF ON ON OFF OFF
45 OFF ON OFF ON ON OFF ON
46 OFF ON OFF ON ON ON OFF
47 OFF ON OFF ON ON ON ON
48 OFF ON ON OFF OFF OFF OFF
49 OFF ON ON OFF OFF OFF ON
50 OFF ON ON OFF OFF ON OFF
51 OFF ON ON OFF OFF ON ON
52 OFF ON ON OFF ON OFF OFF
53 OFF ON ON OFF ON OFF ON
54 OFF ON ON OFF ON ON OFF
55 OFF ON ON OFF ON ON ON
56 OFF ON ON ON OFF OFF OFF
57 OFF ON ON ON OFF OFF ON
58 OFF ON ON ON OFF ON OFF
59 OFF ON ON ON OFF ON ON
60 OFF ON ON ON ON OFF OFF
61 OFF ON ON ON ON OFF ON
62 OFF ON ON ON ON ON OFF
63 OFF ON ON ON ON ON ON
Station address DIP switch
64 32 16 8 4 2 1

Lenze 8400 motec Series Specifications

General

Brand	Lenze
Model	8400 motec Series
Category	DC Drives
Language	English
