Electrical installation
Installation according to EMC (installation of a CE-typical drive system)
4
48
MA 13.0001 DE-EN DE/EN 2.0
4.2 Installation according to EMC (installation of a CE-typical drive system)
Principle circuit diagram
Note!
The described terminal assignment complies with the delivery
status. You can alter the terminal assignment via the operating
software.
( Software Manual 931 E)
Legend to basic circuit diagram
F1, F2 primary-side fusing of the power supply units, consider the rules of conductor
protection
RB external brake resistor
PES large-surface connection of the shield to PE
minimum wiring required for operation
S1 = reversal of rotation direction
S2 = jog value selection
S3 = quick stop
S4 = limit switch 1
S5 = limit switch 2
S6 = controller enable
