Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Display elements and function keys
3
20
EDKVF93−03 EN 2.0
Number
Active level Meaning Explanation
Menu level Menu number Display is only active for operation with
standard devices of the 8200 vector or 8200
motec series
Code level Four−digit code number
Number
Active level Meaning Explanation
Menu level Submenu number Display is only active for operation with
standard devices of the 8200 vector or 8200
motec series
Code level Two−digit subcode number
Parameter value
Parameter value with unit
Cursor
In the parameter level, the digit above the cursor can be directly changed
Function keys
For description see the following table
Function keys
Note!
Shortcuts with :
Press and hold , then press the second key in addition.
Key
Function
Menu level Code level Parameter level Operating level
Change to the
parameter level
Change to the operating
level
Change to the code
level
Go to the "Short setup"
menu and load
predefined
configurations
1)
Accept parameters
when SHPRG or
SHPRG is displayed
Change between menu
items
Change of code number
Change of digit via
cursor
Quick change between
menu items
Quick change of code
number
Quick change of digit
via cursor
!
Change between main menu, submenu and code
level
Cursor to the right
"
Cursor to the left
#
Deactivate the function of the key $, the LED in the key goes off
$
Inhibit the controller, the LED in the key is lit.
Reset fault (TRIP−Reset): 1. Remove the cause of malfunction
2. Press $
3. Press #
1)
Only active for operation with standard devices of the 8200 vector or 8200 motec series
