Troubleshooting and fault elimination
System error messages
General error messages
4

42
EDKVF93−03 EN 2.0
RemedyCauseDescriptionFault message RemedyCauseDescription
DisplayNo.
0073 PR2 Checksum error in parameter
set 2
PLEASE NOTE: The Lenze setting is
loaded automatically!
l Fault while loading a
parameter set.
l Interruption during the
transfer of the parameter set
via keypad.
l Set the required parameters
and save them with C0003 = 2.
The parameters saved do not
comply with the software version
loaded.
In order to be able to
acknowledge the error, first save
the parameter set with C0003 = 2.
0074 PEr Program error Error in the program flow Send the parameter set (on floppy
disk/CD−ROM) with a detailed
description of the problem to
Lenze.
After troubleshooting: Deenergise
the device completely (disconnect
24 V supply, discharge DC bus)!
0075 PR0 Error in parameter set.
The operating system software
has been updated.
Storage of the Lenze setting
C0003 = 1.
After troubleshooting: Deenergise
the device completely (disconnect
24 V supply, discharge DC bus)!
0077 PR3 Checksum error in parameter
set 3
PLEASE NOTE: The Lenze setting is
loaded automatically!
l Fault while loading a
parameter set.
l Interruption during the
transfer of the parameter set
via keypad.
l Set the required parameters
and save them with C0003 = 3.
The parameters saved do not
comply with the software version
loaded.
In order to be able to
acknowledge the error, first save
the parameter set with C0003 = 3.
0078 PR4 Checksum error in parameter
set 4
PLEASE NOTE: The Lenze setting is
loaded automatically!
l Fault while loading a
parameter set.
l Interruption during the
transfer of the parameter set
via keypad.
l Set the required parameters
and save them with C0003 = 4.
The parameters saved do not
comply with the software version
loaded.
In order to be able to
acknowledge the error, first save
the parameter set with C0003 = 4.
0079 PI Fault during parameter
initialisation
l An error has been detected
during the parameter set
transfer between two devices.
l The parameter set does not
match the controller, e.g. if
data has been transferred from
a higher−power controller to a
lower−power controller.
l Correct parameter set.
l Send parameter set (on floppy
disk/CD−ROM) and a detailed
description of the problem to
Lenze.
x083 Sd3 Encoder error at X9
Cable interrupted. Check cable for open circuit.
Pin X9/8 not connected. Apply 5 V to pin X9/8 or switch off
monitoring (C0587 = 3).
x085 Sd5 Encoder error at X6/1 and X6/2
(C0034 = 1)
Current signal at X6/1 X6/2 <
2mA.
l Check cable for open circuit.
l Check current signal encoder.
l Switch off monitoring
(C0598 = 3).
x086 Sd6 Motor temperature sensor error
(X7 or X8)
Encoder for detecting the motor
temperature at X7 or X8 indicates
undefined values.
l Check cable for firm
connection.
l Switch off the monitoring
(C0594 = 3).
x091 EEr External monitoring has been
triggered via DCTRL.
A digital signal assigned to the
TRIP−SET function has been
activated.
l Check external encoder.
l Switch off the monitoring
(C0581 = 3).
0105 H05 Internal fault (memory) Contact Lenze.
