Preface and general information
EDKMF2176X DE/EN/FR 4.2
11
H1vorwrt-2176_Funktion
4 Preface and general information
Please read these instructions and the documentation of the standard device
before you start working!
Observe the safety instructions given therein!
CAN2
CAN1
2176
24V
GND
LO
HI
3
GND
4
5
1
2
Type
Id.-No.
Prod.-No.
Ser.-No.
Hans-Lenze-Straße 1
D31855 Aerzen
Made in Germany
EMF2176IB
L
0
2
4
3
5
1
6
2176_001
Connections
Pos. Description
DC-24-V supply v oltage
Segment CAN2
Segment CAN1
Displays
Pos. Colour Status Description
Red On Fault in segment CAN 2
Green On Transmission of segment CAN 2
Red On Fault in segment CAN 1
Green On Transmission of segment CAN 1
