Venlaon
No venlaon is required for the gearboxes g500-S130 … S220.
The gearbox g500-S220 can oponally be ed with a venlaon unit.
From g500-S400 onwards, the gearboxes are supplied with venlaon units as
standard.
To reduce the number of dierent versions, the following gearboxes can also be ordered with
combined mounng posions:
•
g500-S130 ... S660 in mounng posion M1/5/6 (AEF)
In these gearboxes, the lubricant amount has been opmised for the use in
dierent mounng posions. If required, the breather elements are loosely
enclosed and must be mounted before commissioning depending on the
mounng posion.
4The modular system ^ 10
NOTICE
▶
For gearboxes with venlaon, a gap of at least 30 mm has to be observed to the machine
wall on the corresponding gearbox side.
Informaon on project planning
Final conguraon
Venlaon
33
