Data overview
In order to calculate the exact rao, the number of teeth z
g
(driven) can be divided by the
number of teeth z
t
(driving). These are rounded values.
The rated torque can be gathered from the last digits of the product name e.g.
g500-B110 (110 Nm).
g500-S130, 2-stage
Max. output torque Rao Number of teeth Backlash
Standard
M
2,max
i z
g
z
t
± 20 %
Nm '
63 3.661 637 174 19
76 5.021 728 145 18
87 6.425 559 87 18
92 7.029 5096 725 18
116 8.322 749 90 13
125 9.411 847 90 12
130 11.413 856 75 13
130 12.907 968 75 12
130 14.606 4601 315 12
130 15.979 5992 375 12
130 18.069 6776 375 12
130 20.381 428 21 13
130 23.048 484 21 12
130 24.967 749 30 12
130 28.233 847 30 12
130 31.387 2354 75 12
130 35.493 2662 75 12
130 40.422 1819 45 12
130 45.711 2057 45 12
130 51.230 8453 165 12
130 57.933 869 15 11
130 64.200 321 5 12
130 72.600 363 5 11
102 84.581 8881 105 12
115 95.648 10043 105 11
