Operating instructions i550 motec frequency inverter | 17

Networks

The Ethernet interface of the i550 motec inverter supports the typical topologies and

protocols of one of the following networks, depending on the version:

• EtherCAT

• EtherNet/IP

• Modbus TCP

• PROFINET

The Ethernet interface is designed as an M12 connector:

X396 (IN) / X397 (OUT)

M12 (D coded) Pin Assignment

1 TX+

2 RX+

3 TX-

4 RX-



Housing is connected to functional earth

Electrical installation



















3-phase | 480 V3-phase | 230/240V

3-phase | 400 V

Control connections

Connection diagram

Networks

Functional safety

Safe torque o (STO)

PTC input

Preparation
