Technical data
Electrical data
3

75
EDK94SH366 ZH/EN 3.1
3.2 Electrical data
Input data
Basis of the data
Mains
Voltage
U
LN
[V]
Voltage range
U
LN
[V]
Frequency range
f [Hz]
3/PE AC 400 320 − 0 % ... 440 + 0 % 48 − 0 % ... 65 + 0 %
3/PE AC 500 400 − 0 % ... 550 + 0 % 48 − 0 % ... 65 + 0 %
Voltage Frequency Current [A]
Number of
phases
Type [V] [Hz] max. +45 °C

max. +55 °C

E94ASxE1454 400/500 50/60 140/140 126/126 3
E94ASxE1724 400/500 50/60 166/166 149/149 3
E94ASxE2024 400/500 50/60 195/195 176/176 3
E94ASxE2454 400/500 50/60 237/237 213/213 3
E94ASxE2924 400/500 50/60 280/280 252/252 3
E94ASxE3664 400/500 50/60 354/354 319/319 3
E94ASxE4604 400/500 50/60 444/444 400/400 3
E94ASxE5724 400/500 50/60 553/553 498/498 3
E94ASxE6354 400/500 50/60 614/614 553/553 3
E94ASxE6954 400/500 50/60 672/672 605/605 3
 Temperature in the control cabinet
Output data
Voltage Frequency
1)
Current [A]
Number of
phases
Type [V] [Hz] max. +45 °C

max. +55 °C

E94ASxE1454 0 − 400/500 0 − 599 145/145 131/131 3
E94ASxE1724 0 − 400/500 0 − 599 172/172 155/155 3
E94ASxE2024 0 − 400/500 0 − 599 202/202 182/182 3
E94ASxE2454 0 − 400/500 0 − 599 245/245 221/221 3
E94ASxE2924 0 − 400/500 0 − 599 292/292 263/263 3
E94ASxE3664 0 − 400/500 0 − 599 366/366 329/329 3
E94ASxE4604 0 − 400/500 0 − 480 460/460 414/414 3
E94ASxE5724 0 − 400/500 0 − 480 572/572 515/515 3
E94ASxE6304 0 − 400/500 0 − 480 635/635 572/572 3
E94ASxE6954 0 − 400/500 0 − 480 695/695 626/626 3
 Temperature in the control cabinet
