Elektrische Installation
Anschlussplan
6
EDKRBM001 DE/EN/FR 6.1
21
l
H1_E_INST−ERBx_E_Inst_TXT_DE
Anschlussplan
Variante 1 (kurze Leitungen)
R
B
RB1 RB2
< 0.5 m
T1 T2
+
ERBG008
Verdrillte Leitungen
Variante 2 (lange Leitungen)
R
B
RB1 RB2
<5m
T1 T2
"
"
ERBG007
"
HF−Schirmabschluss durch großflächige PE−Anbindung
Verdrillte Leitungen
Montageschritte
Bauform 1 Bauform 2
ERBMV006 ERBMV007
Bauform 3 Bauform 4
ERBMV008 ERBMV009
