Electrical installation
Connection plan
6
EDKRBM001 DE/EN/FR 6.1
43
l
H1_E_INST−ERBx_E_Inst_TXT_EN
Connection plan
Version 1 (short cables)
R
B
RB1 RB2
< 0.5 m
T1 T2
+
ERBG008
Twisted cables
Version 2 (long cables)
R
B
RB1 RB2
<5m
T1 T2
"
"
ERBG007
"
HF−shield termination by extensive PE connection
Twisted cables
Mounting steps
Design 1 Design 2
ERBMV006 ERBMV007
Design 3 Design 4
ERBMV008 ERBMV009
