Lenze SMVector User Manual

9
SV01N_13418587 EN/DE/ES/FR/IT/PT
Technical Data
240V Three Phase (3/PE) (170...264V); 48...62Hz
Type
Power Mains Current Output Current Heat Loss (Watts)
Hp kW
240V
A
Cont (I
n
)
A
Max I
%
N1/IP31 N4X/IP65
No filter
N4X/IP65
W/ filter
ESV112--2T-- 1.5 1.1 6.9 6 200 64
ESV152--2T-- 2 1.5 8.1 7 200 75
ESV222--2T-- 3 2.2 10.8 9.6 200 103
ESV402--2T-- 5 4.0 18.6 16.5 200 154 139
ESV552--2T-- 7.5 5.5 26 23 200 225 167
ESV752--2T-- 10 7.5 33 29 200 274 242
ESV113--2T-- 15 11 48 42 180 485 468
ESV153--2T-- 20 15 59 54 180 614 591
NOTES:
Output Current: The Output Current Maximum (%) is a percentage of the Output Current Continuous Amps (In) rating
and is adjustable in parameter P171.
400...480VAC Models
400 ... 480V Three Phase (3/PE) (400V: 340...440V), (480V: 340...528V); 48...62Hz
Type
Power Mains Current Output Current Heat Loss (Watts)
Hp kW
400V
A
480V
A
Cont (I
n
)
A
Max I
%
N1/IP31 N4X/IP65
No filter
N4X/IP65
W/ filter
400V 480V 400V 480V
ESV371--4T-- 0.5 0.37 1.7 1.5 1.3 1.1 175 200 23 21 25
ESV751--4T-- 1 0.75 2.9 2.5 2.4 2.1 175 200 37 33 37
ESV112--4T-- 1.5 1.1 4.2 3.6 3.5 3.0 175 200 48 42 46
ESV152--4T-- 2 1.5 4.7 4.1 4.0 3.5 175 200 57 50 54
ESV222--4T-- 3 2.2 6.1 5.4 5.5 4.8 175 200 87 78 82
ESV302--4T-- 4 3.0 8.3 7.0 7.6 6.3 175 200 95
ESV402--4T-- 5 4.0 10.6 9.3 9.4 8.2 175 200 128 103 111
ESV552--4T-- 7.5 5.5 14.2 12.4 12.6 11.0 175 200 178 157 165
ESV752--4T-- 10 7.5 18.1 15.8 16.1 14.0 175 200 208 190 198
ESV113--4T-- 15 11 27 24 24 21 155 180 418 388 398
ESV153--4T-- 20 15 35 31 31 27 155 180 493 449 459
ESV183--4T-- 25 18.5 44 38 39 34 155 180 645 589 600
ESV223--4T-- 30 22 52 45 46 40 155 180 709 637 647
ESV303--4T-- 40 30 68 59 60 52 155 180 1020
ESV373--4T-- 50 37.5 85 74 75 65 155 180 1275
ESV453--4T-- 60 45 100 87 88 77 155 180 1530
NOTES:
Output Current: The Output Current Maximum (%) is a percentage of the Output Current Continuous Amps (In) rating
and is adjustable in parameter P171.
For 400...480 VAC models, the output current maximum (%) in the 400V column is used when P107 = 0
For 400...480 VAC models, the output current maximum (%) in the 480V column is used when P107 = 1
